Mipro ACT-717B 1/2 19″ enkele diversity ontvanger (104 freq.presets)

Mipro ACT-717B 1/2 19″ enkele diversity ontvanger (104 freq.presets)

Artikelnummer: ACT717

390,00  uw inkoopprijs

Alle prijzen zijn exclusief 21% btw

2 op voorraad

  • 1 jaar jaar garantie
  • Gratis verzending v.a. €350,-

Productbeschrijving

Features:
– EIA standard 1/2U rack-mountable metal receiver
– Advanced true diversity technology for best reception quality
– 104 selectable frequencies and 16 preset compatible channels per band
– More with multiple bands
– Industry’s only full-color VFD screen delivers a bright, clear viewing in day/night environment
– Displays Group, Channel, Frequency, Performer’s Name, transmitter battery level, RF, Audio
– SQ level meters, diversity operation, RF interference warning indicator and Lock status
– One-touch Autoscan for a clear, interference-free frequency
– One-touch ACT syncs the transmitter and receiver frequency automatically
– Dual “PiloTone & NoiseLock” circuits minimize interference
– MIPRO RCS.Net software allows real-time computer set up, control and monitoring
– Industry’s only RF interference warning indicator and control for management
– Displays all pertinent parameters on the same screen for easy control and monitoring
– All controls are intuitive and easily setup via a single rotary knob
– RF, audio and transmitter battery status meters
– Superb RF reliability and transparent audio performance
– Receiver provides bias voltage for MIPRO antenna systems
– 100m operating range
– 100% made in Taiwan ensures high product quality and value
– Receiver Bandwidth Narrow
– Channel Single
– Chassis EIA standard 19″ 1/2U
– Display Color VFD displays Frequency, Frequency Code, RF & Audio Meters, Transmitter Battery Meter, Diversity Signals, Interference Warning Indicator
– Programmable User Name, Group, Channel, Squelch Meter, PC Address and Lock Status.



Specificaties

– Frequency Range UHF 480-934MHz
– Bandwidth 24MHz
– Preset Frequencies 104 selectable channels
– Group 1-6 > 8 compatible channels
– Group 7-8 > 12 compatible channels
– Group 9-10 > 16 compatible channels
– Receiving Mode True diversity
– Oscillation Mode PLL synthesized
– Stability +/- 0,005% (-10 – +60C)
– Sensitivity 6dBuV, at S/N>80dB
– S/N Ratio >105dB(A)
– T.H.D. <0.5% @ 1KHz
– Frequency Response 50Hz-18KHz, with high-pass filter
– Squelch “PiloTone & NoiseLock” dual-squelch circuit
– Audio Output Adjustment
– Output level accurately pre-adjusted to equal to the microphone capsule sensitivity
– Maximum Output Level Balanced: +16dBV / 0dBV / -6dB; Unbalanced: +10dBV / 0dBV / -6dB
– Output Connectors Balanced XLR & unbalanced 6,3mm(1/4″)
– Output Switch Single channel output
– Operation Manual or PC remote control via optional software
– Squelch Adjustment Rotary Controller
– Squelch Display VFD Screen
– Power Supply Built-in 100-240V AC Switching Power Supply
– Dimensions 210(W) x 44(H) x 230(D) mm
– Weight Approximate 1.4kg

Notes:
Refer to actual product in the event of product discrepancy.
Frequency range and maximum deviation comply with the regulations of different countries.
