Newhank D-3000 6x 500W/4 Ohm klasse D digitale versterker NIET MEER LEVERBAAR ZIE Blaze PowerZone Connect 2004 EU

Prijs op aanvraag
Newhank D-3000 6x 500W/4 Ohm klasse D digitale versterker NIET MEER LEVERBAAR ZIE Blaze PowerZone Connect 2004 EU

Artikelnummer: D3000


Mail ons voor meer informatie

Productbeschrijving

NewHank D3000 is a 2 unit 6x 500W/4 Ohm class D digital power amplifier.

Features:
– unique and elegant front panel design with brush-finished color
– carefully selected high quality components
– compact structure and light weight
– class D toplogy integrated with switch power supply design
– powerful output and high efficiency
– low electricity consumption
– accurate volume control, switch on/off, signal
– clip and protection LED’s are located on the front panel
– fully automatic protection circuit for each channel including direct current protection
– thermal protection over-load protection and amplitude limit
– variable speed fan controller with temperature sensor
– XLR balance input and professional Speakon output
– stereo, mono or bridge operation



Specificaties

– 4 ohm output power 6x 500W
– 8 ohm output power 6x 300W
– 8 ohm bridged output 3x 1000W
– frequency response (at 1 Watt) 20Hz-20KHz,+0/-1dB
– total harmonic distortion (THD) < 0,2%
– power voltage 220 – 240V – 50/60Hz
– power consumption 2700W
– power connector standard IEC connector
– output grade technology type Class D
– voltage gain 40dB
– damping factor >300/10Hz – 400Hz
– S/N ratio (20Hz-20Khz/4 ohm) > 110dB
– cross talk (1kHZ, 4 ohm) > 35dB
– input sensitivity 0,775dB
– input impedance balanced 20K/ non-balanced 10K
– input connectors XLR socket (female)
– output connectors Speakon
– control knobs Power on/off switch in front panel, gain control in front panel
– mono and bridge selection on rear panel
– Led lights clip/-10dB/signal/Mono/bridge/Status/Active/Protect indication light on front panel
– cooling system fans with variable speed
– protections against short circuit ,over-load, overheat, direct current
– radio-interference , on/off switching, muting, and amplitude limit
– ventilation flow-through ventilation from front to back
– dimensions (WxHxD) 483 x 88 x 357mm
– net weight 11kg
– shipping weight 13,8kg
– accessories operation manual & 1x power cord plug
